The water level float gauge uses a float which moves up and down a displacement transducer to measure slowly changing water levels, typically in flumes or 3D basins. The water level is determined by accurately measuring the distance from the head of the transducer to the magnetic field produced by a magnet mounted inside the float. The advantage of this method is that there is no contact, and therefore no friction, between the float and the transducer.
The transducer consists of a 10mm diameter stainless steel tube, which contains a stretched magnetostrictive wire. The tube is welded to a stainless steel head which contains all the electronics for the transducer.
Probe length
This product has a 300mm probe. 600, 900 and 1200mm probe lengths are available from this website. Other ranges are available on request.
Digital display unit option The user can choose to purchase their water level float gauges equipped with a digital display unit, which shows pressure in a range of parameters.
Key features
Excellent linearity
Versatile display unit
Easy to use
Rugged design
Non contacting
Transducer
Range: 300, 600, 900 and 1200mm (other lengths available on request)
Transducer diameter: 10.5mm
Float diameter: 51mm
Transducer and float material: Stainless steel grade 304
Linearity: 0.05%
Response time: less than 1ms
Transducer supply: 24V DC
Transducer output: 0-10V DC
Cable length: 5m (other lengths available on request)
The ship movement system uses non contacting measurement methods and interfaces directly with HR DAQ acquisition and analysis software. This means that full spectral analysis and also correlation between any of the six degrees of freedom and wave heights or mooring forces can easily be carried out.
Our ship movement system includes:
6 lasers
1 local junction box
30m cable
signal conditioning unit with analogue outputs and power supply
Key features
Compact and easy to set up
0.18mm resolution
Displays all six degrees of freedom
Runs with HR DAQ for logging and analysis
No contact with the ship
Specification:
Laser
Range: 60-140mm
Resolution: 0.3mm
Response: 20 ms
Dimensions: 60 x 80 x 20mm
Mounting: 12mm dia clamp
Power: 3mW
Class: 3B
Cable: 5m
Power supply and interface unit
Voltage: 220V AC (110V AC available on request)
Cable to controller unit: 30m (other lengths available on request)
