Wave Probe Mounting Bracket

Related products

•

  Accessories

  Yaskawa Standard Pendant

  Standard Pendant
  Dimensions	152 mm (w) x 299 mm (h) x 53 mm (d)
  Pendant Display	5.7-inch full-color touch screen, 640 x 480 (VGA)
  Pendant Languages	English, German, Japanese, Spanish, Chinese
  Pendant Weight	.73 kg (1.6 lbs)
  Material	Reinforced plastics
  Coordinate System	Joint, rectangular, cylindrical, tool, 63 user-coordinate frames
  Windows® Menu-Driven Interface	User-selectable touch-screen menu, multiple windows supported;one SD card slot; one USB port (2.0)
  Pendant O/S	Windows Embedded Compact 7
  Protection Rating	IP54
  Programming
  Programming Language	INFORM III, menu-driven programming
  Robot Motion Control	Joint motion, linear, circular, spline interpolation
  Multiple Device Control	Parallel Start, Twin Synchronous, Multiple Group Combinations, Station Coordinated Moves (positioners), Bases (tracks and gantries)
  Programmable Logic Control	Ladder monitor, ladder programming, I/F pendant display, address naming, expanded logic operands
  Maintenance
  Maintenance Functions	System monitor, internal maintenance clocks
  Self-Diagnostics	>Classifies errors and major/minor alarms and displays data; monitors reducers for predictive wear; alerts when major power components reach design life
  User Alarm Display	Displays alarm messages for peripheral devices
  Alarm Display	Alarm messages; alarm history provides instruction of how to repair fault
  I/O Diagnosis	Permits simulated enabled/disabled input/output

  (0 reviews)
•

  Hydraulic Studies and Accessories

  Bends and Fittings Friction

  The equipment measures pressure drops at various flow rates when water flow through different pipe bends, and fittings. It is to be used with Hydraulics Bench i.e. HB100 or HB100N (separately supplied).

  All bends and fittings are connected in series with pressure tappings on both sides of each device. A water manometer with a vent valve and a hand air pump is connected to these tappings. A valve at the outlet is used to control outlet pressure.

  TYPICAL EXPERIMENTS

  • Determination of Pressure Drop across various pipes and fittings at differing flow rates.
  • Estimation of Loss Coefficient (K) or various pipes, pipe fittings and valve settings

  TECHNICAL DATA

  Pipe diameter (nominal)	20 mm.
  Enlarged pipe diameter (nominal)	35 mm.
  Bends	90º Miter bend , 90º small radius bend , 90º large radius bend
  Fittings	90º Elbow , 45º elbows , Sudden expansion , Sudden contraction
  Water manometer	8 tubes x 450 mm x 1 mm graduation
  Software for data display and analysis by computer (separately supplied).
